How To Install Stock ROM On Galaxy S20, S20+, S20 Ultra & S20 5G?

Pin It

Are you in a situation were the only solution left is to install the stock on your Samsung Galaxy S20, S20+, S20 Ultra or S20 5G? If yes, then you have come to the right place because today we are going to have a step by step tutorial on installing the stock rom (Android 10) on your favourite flagship from Samsung.

Even though it's very tricky than the olden times to install firmware using the Odin, it's still possible. Here we will be providing the general firmware installation steps for all Galaxy S20 models, corresponding download links will be also there.

The compatible models are Samsung Galaxy S20 SM-G980F, Samsung Galaxy S20 5G SM-G981B, Samsung Galaxy S20 5G SM-G981N, Samsung Galaxy S20 5G SM-G981U, Samsung Galaxy S20 5G SM-G981U1, Samsung Galaxy S20 5G SM-G981W, Samsung Galaxy S20+ SM-G985F, Samsung Galaxy S20+ 5G SM-G986B, Samsung Galaxy S20+ 5G SM-G986N, Samsung Galaxy S20+ 5G SM-G986U, Samsung Galaxy S20+ 5G SM-G986U1, Samsung Galaxy S20+ 5G SM-G986W, Samsung Galaxy S20 Ultra SM-G988B, Samsung Galaxy S20 Ultra SM-G988N, Samsung Galaxy S20 Ultra SM-G988U, Samsung Galaxy S20 Ultra SM-G988U1 and Samsung Galaxy S20 Ultra SM-G988W.

So lets proceed with the steps.

Advertisement

However before proceeding please make sure that you have made a complete backup of your phone memory so that you can recover from a worst case scenerio.

Steps To Install Stock ROM/Firmware On Samsung Galaxy Galaxy S20, S20+, S20 Ultra & S20 5G Using Odin

1. First you need to download and install the Samsung USB drivers. You can do that it from the below link;

2. Now we need to enable the developer options, USB debugging and perform the OEM unlock on your S20.

To enable "Developer Options" on your Galaxy Smartphone goto Settings>About phone>Software Information, and tap on the “Build number” 10 times until you get a message that you are a “developer.". Now you will see an additional menu entry in the "Settings" menu called "Developer Options" as shown below.

Once you have enabled the "Developer Options" tap on it and you will see a similar screen as shown below (These are from One UI 1.5, if your UI version is something else slight difference maybe there).

Now tap on "OEM unlocking" and "USB debugging" to enable it. If  you get a popup warning, tap enable if you would like to proceed.

3. Once done you need to download the firmware files and the Odin app.

Please download the files corresponding to your phone from the below links;

You may need to login/create a free account to download the files. Also make sure that your phones bootloader is not locked by any carrier if so, please unlock it first.

Once downloaded please extract it and you will get similar files like given below;

4. Now download the Odin app from the below link;

When the download has finished please extrat the file to your PC desktop and open the "Odin..xxx.exe" file.

5. In the next step you need to enter your Galaxy Galaxy S20, S20+, S20 Ultra or S20 5G into the "download mode".

For that first you need to switch of your Galaxy S20 device. Now switch it back on and when you see the "Samsung" logo on the scren press and hold "Volume Down + Volume Up" and connect your mobile with your PC using a USB data cable.

Now when you get the warning message on your phone screen release all the buttons and press "Vol Up" key to enter into the "Download mode".

6. Now go back to your Odin window which looks similar to the screenshot below;

In the next step select the extracted firmware files (done in step-3) corresponding to each buttons in the odin app. For example click on button "CP" and select the extracted firmware file which starts with "CP". Same way click on "AP" and and select the extracted firmware file which starts with "AP". Similarly, add BL file in the BL button.
If you want to factory reset while you install stock firmware select "CSC" file after you click the CSC button, otherwise, load the "HOME_CSC" instead.
Make sure F.Reset.Time and Auto Reboot option are checked in the Odin's "Options" tab.

Ignore the last button on Odin which is "UMS" or "USERDATA".

7. Once everything is done as mentioned above, click the "Start" button in the Odin app and wait for the installation process to get completed. Finally when the process is finished your Galaxy S20, S20+, S20 Ultra or S20 5G will reboot and you will get a "Pass" message from the Odin app.

That's it friends, you have successfully installed the Stock ROM/Firmware (Android 10) on your Samsung Galaxy Galaxy S20, S20+, S20 Ultra or S20 5G.

Normal queries for this tutorial

  • How to install stock rom (Android 10) on Samsung Galaxy S20 SM-G980F?
  • How to install stock rom (Android 10) on Samsung Galaxy S20 5G SM-G981B?
  • How to install stock rom (Android 10) on Samsung Galaxy S20 5G SM-G981N?
  • How to install stock rom (Android 10) on Samsung Galaxy S20 5G SM-G981U?
  • How to install stock rom (Android 10) on Samsung Galaxy S20 5G SM-G981U1?
  • How to install stock rom (Android 10) on Samsung Galaxy S20 5G SM-G981W?
  • How to install stock rom (Android 10) on Samsung Galaxy S20+ SM-G985F?
  • How to install stock rom (Android 10) on Samsung Galaxy S20+ 5G SM-G986B?
  • How to install stock rom (Android 10) on Samsung Galaxy S20+ 5G SM-G986N?
  • How to install stock rom (Android 10) on Samsung Galaxy S20+ 5G SM-G986U?
  • How to install stock rom (Android 10) on Samsung Galaxy S20+ 5G SM-G986U1?
  • How to install stock rom (Android 10) on Samsung Galaxy S20+ 5G SM-G986W?
  • How to install stock rom (Android 10) on Samsung Galaxy S20 Ultra SM-G988B?
  • How to install stock rom (Android 10) on Samsung Galaxy S20 Ultra SM-G988N?
  • How to install stock rom (Android 10) on Samsung Galaxy S20 Ultra SM-G988U?
  • How to install stock rom (Android 10) on Samsung Galaxy S20 Ultra SM-G988U1?
  • How to install stock rom (Android 10) on Samsung Galaxy S20 Ultra SM-G988W?

If you have faced any issues while trying to install Stock ROM on Samsung Galaxy S20, S20+, S20 Ultra or S20 5G, please feel free to post it in the comment section below, don't worry I will help you as fast as I can.

If "How To Install Stock ROM On Galaxy S20, S20+, S20 Ultra & S20 5G?" tutorial really helped you, please give a like/share on social networking websites by using the below given buttons.

Advertisement

Pin It

You May Also Like

Comments

My S20+ ROM is 5G SM-G986N, can I change to SM-G9860 ROM according to above step?
Will it become brick after install SM-G9860 ROM?
Thanks.
Reply Reply with quote
Please make a phone backup and try.
Reply Reply with quote
IT KEEP SAYING Complete (write) operation failed. all threads completed (success 0/ failed 1)
Reply Reply with quote
Please make sure that your phone's bootloader is not locked.
Reply Reply with quote
